SLD-003
Single Pattress 150W lighting dimmer module (trailing edge) with 2 x push buttons and indicator LEDs and 2 x general purpose digital inputs
Actual product appearance may vary
£48.00 ex VAT
(£57.60 inc VAT)
Shipping not included
This module is an improved version of the previous SLD-002, suited to inline (no Neutral required) control of dimmable LED lighting. It provides trailing edge dimming control for a single lighting circuit in a convenient single pattress format. The two buttons allow on/off and brightness control and can also be assigned to other functions. Two indicator LEDs may be associated with button functions or used for other purposes.
Two digital inputs are included which can be used for a wide range of purposes such as door and window sensors, external PIR devices or any other volt-free contact closure.
A datasheet for the SLD-003 is available here.
Product Specifications
- Format:
- Single Pattress
- Programmable Buttons:
- 2
- Programmable LEDs:
- 2
- Dimmer Channels:
- 1
- Digital Inputs:
- 2
- Dimmer Rating:
- 150W
- Special Features:
- Board temperature sensing
